Prestige Sugatsune Multi Purpose Soft Closing Bin Chute - 308mm
- Flange lip: 1.2 mm
- Outer Dimensions (mm): H234 x W308
- Inner Dimensions (mm): H160 x W234
- Hole cut: H215mm x W267mm
- Satin Stainless Steel finish
- Ideal for a wide range of waste products
- Suitable for counter top - horizontal installations only
Prestige Sugatsune Multi Purpose Soft Closing Bin Chute - 308mm
Quality undercounter mounted rectangle waste chute with soft closing lid. The damper mechanism ensures that the close function takes safety into account.
The lid closes slowly and smoothly when released with no sharp edges. The maximum disposal opening area is H215mm x W265mm suitable for a wide range of waste products.
This quality chute is made from 304 Grade Stainless Steel suitable for domestic, busy kitchens, wet or humid areas.
The waste chute is suitable for horizontal installations only. It provides discreet access to under-counter waste receptacles (not included). This can be also be installed on an angle of 85-46 degrees.
- Made of 304 stainless steel
- Resistant to rust
- Can be used around water
- Slow, soft closing lid mechanism
- No sharp edges
- Disposal waste area: H215mm x W267mm
- No unpleasant noise when lid closes
- Flange lip: 1.2 mm
- Outer Dimensions (mm): H234 x W308
- Inner Dimensions (mm): H160 x W234
- Hole cut: H215mm x W267mm
- Satin Stainless Steel finish
- Ideal for a wide range of waste products
- Suitable for undercounter mounted installation - horizontal installations only
- Certified ISO 14001
| SKU | AZ-GD232-HL |
|---|---|
| Finish | Satin Steel |
| Height (mm) | 234 |
| Outer Dimensions (mm) | 308 x 234 |
| Inside Dimensions (mm) | 234 x 160 |
| Waste disposal area (cm2) | 234 x 160 |
| Hole cut out diameter (mm) | H215 x W267 |
| Steel gauge (mm) | 1.2 |
| Installation | Horizontally Installation only |
| Steel Type | 304 |
| Weight (kg) | 2.2 |
| EAN: | 4510932165808 |
This discreet chute is ideal for any waste items 265mm x 215mm in size, eg. sandwich boxes, large bottles and general waste products. This quality chute is ideal for busy professional kitchens or for use at home.
Can you trap fingers in this chute?
This chute lid has no sharp edges and closes very slowly. This quality chute was designed with safety in mind.
Is the lid a tight seal around the rim?
No there is a small gap of 2 mm around the rim as shown on the image.
Where is this product manufactured?
Japan.
Can this be installed on an angle?
As long as the chute is fitted horizontally, it can be angled at 85 to 46 degrees.
| SKU | AZ-GD232-HL |
|---|---|
| GTIN | 4510932165808 |
| Weight | 2.000000 |
| Warranty | 10 Years Warranty |
| Quick Code | 7527 |
| Manufacturer | Prestige |
| Delivery | 1-2 Working Days |
